Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer

Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer

Products - Rock Breaker Parts
  • Highlight

    HP20 hydraulic rock breaker

    ,

    powerful construction machinery hammer

    ,

    efficient crushing hydraulic breaker parts

  • Applicable Industries
    Construction Work, Mining
  • Product Name
    Breaking Hammer
  • Color
    Yellow
  • Model
    HP20
  • Type
    Hydraulic Parts
  • Health Status
    100%new
  • Place of Origin
    China
  • Model Number
    HP20
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiable
  • Packaging Details
    Neutral packing
  • Delivery Time
    3-7day
  • Payment Terms
    L/C, D/P, T/T, Western Union

Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer

Get Price Contact Now

Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer



Product name Excavator Breaking Hammer
Model HP20
Origin China
Color Yellow
Applicable industries repair shops, retail, construction sites, energy and minerals
Payment term T/T, Western Union, PayPal, L/C
FOB port Guangzhou, Shenzhen

Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 0Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 1Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 2Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 3Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 4Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 5


Our excavator hydraulic hammers are available from ~ 50 kg to more than 10,000 kg of operating weight for any kind of carrier. Over sixty years of development of the breaker hammers has produced advances at different levels, such as self-lubricating systems, sound & vibration damped systems, automatic rock hardness adjusting systems, energy recovery, solid body concept and much more.
Product Paramenters
Light Hydraulic Breaker
ltem/Model
HPS40
HPS45
HPS53
HPS60
HPS68
HPS75
HPS85
HPS100
Weight(kg) Side/Top/Silenced
70/72/102
95/95/129
158/158/165
190/180/231
275/300/400
380/409/450
500/580/680
761/866/1007
Operating Pressure(kg/c㎡)
90-120
90-120
90-120
100-130
100-140
120-150
130-160
150-170
Required Oi Flow(L/min)
15-30
20-40
25-55
30-60
40-70
50-90
60-100
80-110
Impact Rate(bpm)
800-1400
700-1200
600-1250
500-1000
500-900
400-800
400-800
350-700
Hose Size (inch)




1/2
1/2

3/4
Chisel Diameter(mm)
40
45
53
60
68
75
85
100
Excavator Weight(ton)
0.8-2.5
1.2-3.0
2.0-4.5
3.0-5.5
5.0-7.0
6.0-9.0
7.0-14
11-16

Medium Hydraulic Breaker
Item/Model HPS125 HPS135 HPS140 HPS140A HPS150
Weight(kg) Side/Top/Silenced 1277/1308/1371 1688/1868/1918 1770/1800/2004 1805/2090/2042 2218/2380/2457
Operating Pressure(kg/c㎡) 150-170 160-180 160-180 160-180 180-200
Required Oi Flow(L/min) 90-120 100-150 120-180 120-180 150-190
Impact Rate(bpm) 350-650 400-800 350-700 350-700 350-650
Hose Size (inch)     1 1
Chisel Diameter(mm) 125 135 140 140 150
Excavator Weight(ton) 15-18 16-21 18-26 18-26 27-35
Heavy Hydraulic Breaker
Item/Model HPS155 HPS165 HPS175 HPS185 HPS195
Weight(kg) Side/Top/Silenced 2577/2754/2968 2751/2916/3165 3902/3910/4470 4227 4867
Operating Pressure(kg/c㎡) 180-200 180-220 180-220 180-220 180-220
Required Oi Flow(L/min) 180-240 200-260 210-290 220-270 220-270
Impact Rate(bpm) 300-450 250-400 200-350 200-250 180-200
Chisel Diameter(mm) 155 165 175 185 195
Excavator Weight(ton) 28-36 30-40 38-50 42-55 45-70



Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 6

We also operate:

Excavators Engine Overhaul Kits,Excavator Electrical Parts,Diesel Fuel Injectors,Excavator Filters,Excavator Solenoid Valve,Excavator Control Panel,Excavator Engine Parts,Excavator Turbocharger,Excavator Starter Motor,Excavator Seal Kits,Excavator Hydraulic Parts,Handok Hydraulic Pump,Excavator Gearbox,Rock Breaker Parts.



Construction machinery rock breaker parts HP20 powerful efficient hydraulic breake crushing hammer 7

FAQ



Q1: Wonder if you accept small orders?
A1: Do not worry. Feel free to contact us .in order to get more orders and give our clients more convener ,we accept small order.



Q2: Can you send products to my country?
A2: Sure, we can. If you do not have your own ship forwarder, we can help you.



Q3: Can you do OEM for me?
A3: We accept all OEM orders,just contact us and give me your design. we will offer you a reasonable price and make samples for you ASAP.



Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.



Q5: How long is your production lead time?
A5:It depends on product and order qty. Normally, it takes us 15 days for an order with MOQ qty.



Q6. Do you test all goods before delivery?
A6: Yes, we have 100% testing before delivery.
